- Crystal-clear, high-quality stereo audio
- Advanced AI-powered 4K camera
- Simplified installation
- Sound investment: fewer interventions, minimized downtime, future-proof platform
- Carbon-neutral product
Specifications
- Operating System Compatibility:
Windows 10 and higher, macOS 11 (Ventura) and higher, Android v13+ (ClickShare App), iOS 16+ (ClickShare App) - System Requirements for Optimal Performance with Microsoft Teams or Zoom:
- Minimum: Intel i3 dual-core processor or AMD Ryzen 7, 8GB RAM, Windows 10 (latest build) or macOS Mojave (latest build)
- Recommended: Intel i5 4-core processor or AMD Ryzen 9, 8GB RAM, Windows 11 (latest build) or macOS (latest build)
- Video Output:
4K UHD (3840*2160) @ 30Hz via HDMI™ 1.4b or USB-C DP ALT mode (DisplayPort 1.2) - Video Input:
None - Camera:
4K resolution, 3x zoom/ePTZ, 120˚ field of view - Camera AI Features:
Group framing and composition mode for up to 4 people - Audio Output:
2x 10W full duplex and stereo speakers with 8 Ohms impedance (available mid 2024) - Audio Pickup:
6 beamforming MEMS microphones with echo and background noise cancellation, with a pickup range of up to 15 feet (4.5 meters) - ClickShare Buttons:
1 - ClickShare App:
Available for desktop and mobile - Native Protocols:
Airplay, Google Cast, Miracast (available mid 2024) - Simultaneous Screen Sources:
1 - Noise Level:
Fanless - Authentication Protocol:
WPA2-PSK in stand-alone mode, WPA2-PSK or IEEE 802.1X with ClickShare Button in network integration mode - Wireless Transmission Protocols:
IEEE 802.11 a/g/n/ac, IEEE 802.15.1 - Wireless Range:
Up to 30m (100 ft) between ClickShare Button and ClickShare Bar - Frequency Bands:
2.4 GHz and 5 GHz (DFS channels supported in selected countries for network integration mode) - Connections:
1x USB-C 3.1 (DP) to screen, 1x USB-A 2.0, 1x Ethernet LAN 1Gbit, 1x USB-C 2.0 (side) - Temperature Range:
- Operating: 0°C to +40°C (+32°F to +104°F)
- Max: 35°C (95°F) at 3000m
- Storage: -20°C to +60°C (-4°F to +140°F)
- Humidity:
- Storage: 0 to 90% relative humidity, non-condensing
- Operation: 0 to 85% relative humidity, non-condensing
- Anti-Theft System:
Kensington lock (back and bottom) - Certifications:
FCC/CE - Touch Screen & Interactivity:
Not supported - Wireless Conferencing:
Via App or Button - Local View:
Supported - Network Connection:
LAN & WiFi - Management and Reporting:
Supported - Warranty:
1-year standard, extendable to 5 years with SmartCare registration - Dimensions (HxWxD):
98 mm x 640 mm x 101 mm - Power Consumption:
- Operational: 5-20W
- Maximum: 65W
- Power Supply:
Standard 110/220 V AC plug or USB-C (back) - Weight:
2500g
